The machine is in good technical condition, after prior agreement the possibility of testing. Left spindle: - Spindle bore 62 mm (tension tube 52 mm) - Clamping cylinder with short stroke KITAGAWA type SS1452 - speed 6'500 rpm - Passage in cylinder and draw tube 51 mm - KITAGAWA collet chuck type CRL60-A6 for F66 collets Right spindle: - spindle drilling 53 mm - Clamping cylinder with short stroke KITAGAWA type SS1452 - speed 6'500 rpm - Three-jaw chuck KITAGAWA type BB206 “, diameter 170 mm, passage 53 mm for max. Speed 6000 rpm. Tool equipment: The machine is equipped with the following tools: Tools according to arrangement Accessories: - Mayfran heavy chip conveyor, ejection along the axis of rotation, ejection height 1100 mm - Complete cooling system with high pressure pump, ARO cooling belt filter with separate additional tank of 500 liters - Multi-bar magazine Hydrobar Sprint S3 / 3M (LNS) Additional equipment: - Power increase to 22 kW on both spindles - two manually operated measuring arms for determining tool offsets for the left and right spindles - Workpiece unloader for counterspindle with gripper, linear axis in the working area, max. workpiece weight 7 kg - Conveyor belt for removing the workpiece length 1,500 mm, width 250 mm - Automatic shutdown - Spare tool strategies: acquisition of sister tools through cutting time, monitoring of cutting pressure or tool offset value - 8 more M functions - 2 high pressure pumps type BFS238 / 100, 22 l / min at 10.0 MPa - Flushing the spindle via the right spindle using a high-pressure pump - Pneumatically controlled collection of the workpiece and removal of rod residues, Ø65mm x 130mm, collection container mounted on the front door - Possibility to switch the pressure from 1.5 to 10.0 MPa for both revolvers - Losma Darwin 2000D oil and mist separator - Ejection department for finished part and raw material - Belt filtration system type P 750/1500 E3 -T1 - Diagnostic system, including the whole machine, including monitoring of all lubrication and hydraulic system
