Lathes - CNC

LZ 02RY

Basic information about the machine::

Inv. číslo:
28294
Výrobce:
MYIANO
Rok výroby:
2005
Lokalita:
CZ

Machine parameters:

Description:

The machine is in good technical condition and can be tested by prior arrangement. The machine (including chip conveyor) is 290x235 cm and weighs 3500-4000 kg. Transformer station: 65x60 cm, 150 kg Max. Turning Length: 81.3 mm Max. Turning Diameter: 99.1 mm CNC Type: Fanuc 21iT X-Axis: 300 mm Z-Axis: 240 mm Spindle Nose: A2-6 Spindle Bore: 33 mm Number of Tools on Turret: 8 Number of Live Tools: 10 Adjustable Speed: 4000 rpm Spindle Motor Power: 11 kW Tailstock: No Bar Feeder: No Dimensions (L x W x H): 2600.0 × 2300.0 × 2400.0 mm Weight: 3900 kg

Photogallery:
